High Frequency Rotary Drum Sieve Machine
video
High Frequency Rotary Drum Sieve Machine

High Frequency Rotary Drum Sieve Machine

Rotary Drum screen has wide range of Sieving and dewatering sizes and capacities, Mining Machinery Rotating Vibrating Drum screen is a mechanical screening machine used to separate materials.

Description

High Frequency Rotary Drum Sieve Machine


This High Frequency Rotary Drum Sieve Machine is a large capacity, high efficiency powder screening machine, widely used in fertilizer plants, you can use it to separate finished products and returned materials. Whether the material is wet or dry, it can fully rotate and screen the material, and has the drying function. In addition, its rotary brush can keep the sieve clean and tidy, thus providing you with a dust-free working environment.


High Frequency Rotary Drum Sieve Machine


High Frequency Rotary Drum Sieve Machine Features


The biggest advantage of the high frequency drum screening machine is its unique structural design, with a bouncing ball inside, which can automatically clean up materials when in use to avoid annoying blockage. And its unique screen frame structure can make the screen use longer, effectively reduce excessive maintenance times, and greatly save your time and energy. Finally, the spare parts of the machine are modular, which can be replaced quickly and reduce downtime in case of problems.


High Frequency Rotary Drum Sieve Machine Factory

heavy duty rotary drum sieve



High Frequency Rotary Drum Sieve Machine Industrial Applications

rotary drum sieve machine application


High Frequency Rotary Drum Sieve Machine Technical Parameters


Model

Power

Cylinder Diameter

Cylinder Length

Inclination

Input Size

Dimension (L×W×H)

Weight

(kw)

(mm)

(mm)

°

(mm)

(mm)

(kg)

GTS1015

3

1000

1500

≤300

2600×1400×1700

2200

GTS1020

4

1000

2000

3390×1400×2140

2800

GTS1225

5.5

1200

2500

4146×1600×2680

4200

GTS1530

7.5

1500

3000

4460×1900×2820

5100

GTS1545

11

1500

4500

≤400

5960×1900×3080

6000

GTS1848

15

1800

4800

6500×2350×4000

7500

GTS2055

22

2000

5500

7500×2550×4800

9600

GTS2265

30

2200

6500

8500×2750×5000

12800
